Product Details
Harvesting grass
Xinlian brand hay rake is a type of machinery used for harvesting grass that is scattered on the ground and converting it into hay strips. The purpose of raking is to allow the grass to dry thoroughly and facilitate the collection of dry hay. According to the relationship between the direction of the hay strips and the forward direction of the machine, hay rakes can be divided into two major categories: horizontal and lateral. The integrated hay strips are parallel to the forward direction of the machine. The shape of the hay strips is neat, loose, and uniform. The distance the grass moves is small, and there are few impurities. It is suitable for high-yield natural grasslands and artificial pastures.
The Xinlian brand hay rake is composed of a flexible and durable frame, which is suitable for any type of land, even extremely uneven land or slopes. The rake wheels are the main components of the hay collector. Each rake wheel is independent and includes shock-absorbing springs that can reduce the vibration of the rake wheel, allowing the wheels to perfectly adhere to the ground. Features of the Xinlian brand hay rake: (1) A very simple and efficient rake design concept – applicable to various feed grass. (2) The spring suspension system of the rake wheels enables it to be suitable for various types of pastures and operates without damaging the pasture environment under normal pressure. (3) The rake wheels, which are independent and replaceable, are installed on the cone gears.
|
Model number
|
9L-4.5
|
9L-5.4
|
9L-7.5
|
9L-9.0
|
|---|---|---|---|---|
|
Overall weight of the machine
|
650 kilograms
|
750 kilograms
|
850 kilograms
|
1400 kilograms
|
|
enforce standards
|
JB/T7766.1-2011
|
JB/T7766.1-2011
|
JB/T7766.1-2011
|
JB/T7766.1-2011
|
|
Supporting power
|
Tractors with a horsepower of 20 or above
|
Tractors with a horsepower of 30 or above
|
Tractors with a horsepower of 48 or above
|
Tractors with a horsepower of 60 or above
|
|
The traveling speed of the unit
|
12 - 15 kilometers per hour
|
12 - 15 kilometers per hour
|
12 - 15 kilometers per hour
|
12 - 15 kilometers per hour
|
|
Working range
|
4.5m
|
5.4m
|
7.5m
|
9.0m
|
|
Number of teeth on the gear plate
|
80（40or60）
|
80（40or60）
|
80（40or60）
|
80（40or60）
|
|
Number of dials
|
6 plates
|
6 plates
|
6 plates
|
6 plates
|
|
Width of the grass strip
|
0.7-1.8m
|
0.7-1.9m
|
0.7-1.9m
|
0.7-1.9m
|
|
Transportation status dimensions
|
4300*3350*3300
|
5300*3350*2300
|
6800*3450*2300
|
8200*3550*2300
|
The above parameters are subject to change without prior notice! For the latest information or custom product requirements, please contact our customer service team for inquiries and quotations.
