Product Details
Double disc mower
This product can directly feed silage, various hay bales, straw and other fibrous feeds into the mixer for chopping, mixing. The mixing speed is fast. There are multiple specifications (5-20 cubic) that can be customized according to the needs of the ranch.
The cutting and mixing time for each batch of feed is about 30 minutes. Depending on the volume of the box, each feed mixer can feed 200 to 2,000 dairy cows per day, which can replace the work of 20 to 200 workers, reducing the labor intensity of the workers and improving the feeding efficiency.
|
Model number
|
XL-140
|
XL-165
|
|---|---|---|
|
Matching power (horsepower）
|
Parallel bars 15-18
|
Multi-cylinder 45-60
|
|
Cutting width (m)
|
1.4
|
1.65
|
|
Number of discs (pieces)
|
2
|
2
|
|
Work efficiency
|
6-8
|
15
|
|
Number of shears (pieces)
|
6
|
6
|
Tractor-mounted disc mower (parameters)
|
Disc lawn mower
|
1670
|
2050
|
2450
|
|---|---|---|---|
|
Cutting width
|
1.67m
|
2.05m
|
2.45m
|
|
Number of discs
|
4
|
5
|
6
|
|
Disc speed
|
2900
|
2900
|
2900
|
|
Disc cutting diameter
|
19.7in.（500mm）
|
19.7in.（500mm）
|
19.7in.（500mm）
|
|
Moving speed
|
4 - 12 kilometers
|
4 - 12 kilometers
|
4 - 12 kilometers
|
|
Supporting power
|
40hp-55hp
|
55hp
|
75hp
|
|
PTO suspension
|
Cat1-2
|
Cat1-2
|
Cat-2
|
|
Weight
|
400kg
|
500kg
|
625kg
|
The above parameters are subject to change without prior notice! For the latest information or custom product requirements, please contact our customer service team for inquiries and quotations.
